Infographic Scientific Process Flow Step 1) Offshore Oil Platform (source Of Oily Wastewater) Step
Description
Infographic, scientific process flow: Step 1) Offshore oil platform (source of oily wastewater). Step 2) Sample collection arrow pointing to a laboratory beaker with murky fluid. Step 3) Chemical injection with a micropipette, chemical symbols shown. Step 4) Final separation: oil on top, clean water below, with a checkmark icon. All steps connected by arrows on a single timeline. Technical drawing style, isometric perspective, blue and green color theme.
Created On
22.12.2025 14:39
